Get Mechanical with DraftSight Deliver Innovative Products Faster

Save time and operating costs with the ability to intelligently create, manage, share, and update mechanical drawings that contain or require traditional mechanical components in DWG format — using robust solutions from the makers of SOLIDWORKS®.


You have the flexibility to manage DWG data on premises with DraftSight Mechanical, or on the cloud with DraftSight Mechanical connected to the 3DEXPERIENCE® platform.


Take product development to the next level. Deliver on time. Stay under budget.

    • Ensure Bill of Materials (BOM) accuracy with support for part references.
    • Modify existing part references and create new ones leveraging the hardware library or user defined custom blocks.
    • Reduce operating costs by documenting accurate parts lists and assembly instructions.
    • Annotate and label drawings by creating and organizing balloons associated with parts lists.
    • Create 2D drawings that meet international drafting standards ANSI, ISO, DI, JIS, and BSI.
